LUW F

LUW_SF_10179_AW.eps

Ducting Angle LUW F M 8

Group: 1605

Part number 113331

Ducting Angle for a direct installation to the flange of rectangular ventilation ducts without duct penetration

Prevents flow losses, leaks and flow noise, meets hygiene requirements in accordance with VDI 6022

Technical Data
Installation

Technical Data

LUW_F_M.eps

B	35 mm
b	10,5 mm
H	52 mm
H₁	45 mm
L	41 mm
L₁	17,75 mm
M_a	M8

Load range

-V_Z,perm.

0,80 kN

Technical specifications

Material base body	steel
Surface	electro galvanized (Fe//Zn)
Corossion class	C2

Certification

Installation

The ventilation duct could be connected directly to the pre-assembled grub screw.
