Insulated Foot Plate SHB 600 HCP
Group: 1877
Part number 113120
Integrated footplate provide a solution for the support of building services
Permeable rubber compound mat to provides secure support and even load distribution
Technical Data
BP1 | 98 mm |
bP | 11 mm |
IZP | 33 mm |
Ma | M10 |
tP | 8 mm |
TS | 15 mm |
Technical specifications
Fire Performance | B2 according to DIN 4102 |
Tensile Resistance | 0,40 N/mm² |
Tear Resistance | 3,40 N/mm |
Elongation at break | 70 % |
Compression set | approx. 4.5 % measured 30 min. after release at 50 % compression / 23°C after 72 hours |
Material base body | steel |
Material insulation body | caoutchouc |
Material connecting element | steel |
Surface | HCP |
Corossion class | C4 |
Certification
Installation
Unscrew the nuts, position the distance between the screws according to the slot pattern of the element to be connected and tighten screws.
Following elements could be assembled to the Insulated Foot Plate: Slide Elements, Mounting Plates, Support Brackets 150/150, Joints JOI 41 T, Channels MS 41, Cantilever Brackets, End Supports WBD for single channel.
The system-related static friction must be determined on site. Depending on the roofing membrane used, the use of an additional separating layer is recommended. The load transfer into the structure must be checked on site.
