Type 0
Sound Absorber SDE 0
Group: 1610
Versatile sound insulation element for ventilation systems with sound insulation requirements according to DIN 4109
Mainly for direct ceiling attachment, can be combined with various mounting components
Overview of Types
General Information
May be used for ventilation systems and other M&E services, mainly for direct ceiling attachment. Can be combined with other support components such as Ducting Angles, Pipe Clamps, Channels or special structures. May also function as an efficient band hanger when turned by 180°.
Certification
Technical specifications
Max. temperature | 110 °C |
Min. temperature | -50 °C |
Fire Performance | B2 according to DIN 4102 |
Insertion Isolation | 15 dB(A) |
Hardness | 45+/-5° Shore |
Material base body | steel |
Material insulation body | SBR/EPDM |
Surface | electro galvanized (Fe//Zn) |
Corossion class | C2 |
Load range
Type | -VZ,perm. |
SDE 0-M 8 | 1,00 kN |
SDE 0-M10 | 1,00 kN |
