Welding Plate SPL UNI HCP
Group: A430
Part number 113636
Can also be mounted on the TP F beam sections for larger attachment surfaces
Can also be mounted on the TP F beam sections for larger attachment surfaces
Technical Data
BP | 370 mm |
BP1 | 300 mm |
BP2 | 260 mm |
BP3 | 62 mm |
bP1 | 14 mm |
dP | 14 mm |
HP | 370 mm |
HP1 | 300 mm |
HP2 | 160 mm |
HP3 | 50 mm |
IZP1 | 65 mm |
tP | 12 mm |
Technical specifications
Primary element material | steel |
Surface finish | HCP |
Corrosion protection class | C4 |
Certification
Installation
Depending on the type, different installation methods are recommended:
a) Installation of SPL universal with Flange Screws SCR FLA TT M10 x 30 (part no. 116479) to Beam Section TP F.
b) Installation of SPL universal by means of 1 Assembly Set 5P M12 S to primary steel with flange width between 100 and 300 mm.
