Fixing Bracket MW S 70/40/90°
Group: 1326
Part number 191963
Direct, lateral mounting to concrete or wooden beams and trusses
Connecting bracket for frame constructions made of profiles
Choose your country
Go to your local Sikla page and discover offers for your country or sales region:
Country
MW S 70/40/90°
Group: 1326
Part number 191963
Direct, lateral mounting to concrete or wooden beams and trusses
Connecting bracket for frame constructions made of profiles
B | 41 mm |
b | 10.5 mm |
d | 10.5 mm |
H | 70 mm |
H1 | 34.6 mm |
L | 41 mm |
L1 | 17.5 mm |
t | 1.5 mm |
VZ,perm. | 2,00 kN |
Primary element material | steel |
Surface finish | electro galvanized (Fe//Zn) |
Corrosion protection class | C2 |
See supplementary document
