Plug-in component designed to create an endplate at the open end of a Beam Section TP F80 or a Cantilever bracket AK F80. By means of the round holes in the base plate a direct connection to excisting cast-in channels is possible.

Plug-in component designed to create an endplate at the open end of a Beam Section TP F 100 or a Cantilever bracket AK F 100. Variation types F 100-80 (E) are designed to combine F 100 with F 80 beam sections. Octagonal insert allows full utilisation of beam section within the space required by the End Support STA itself.

Plug-in component designed to create an endplate at the open end of a Beam Section TP F80 or a Cantilever bracket AK F80. By means of the round holes in the base plate a direct connection to excisting cast-in channels is possible.

The End Support STA F 100-80-E 45° is designed to generate a 45° bracing element in combination with F100 Beam Sections or F100 Cantilever Brackets.

Plug-in component designed to create an endplate at the open end of a Beam Section TP F 100 or a Cantilever bracket AK F 100. Variation types F 100-80 (E) are designed to combine F 100 with F 80 beam sections. Octagonal insert allows full utilisation of beam section within the space required by the End Support STA itself.

In combination with a Sikla Channel MS 41, End Support WBD is particularly suitable for setting up support structures attached to walls, floors and ceilings as a base for frame structures made of Sikla Channels. The generous dimensions and the diamond shape of the mounting plate provide a high bending moment and safely stabilise lateral loads.

In combination with a Sikla Channel MS 41, End Support WBD is particularly suitable for setting up structures attached to walls, floors and ceilings as a base for frame structures made of Sikla Channels. The generous dimensions and the diamond shape of the mounting plate provide for a high bending moment and safely stabilise lateral loads. The HCP design allows for use in areas with higher corrosion protection requirements.

Plug-in component designed to create a square end plate at the open end of a Beam Section TP F80 or a Beam Bracket/Cantilever bracket AK F80. Variation 'T' with octagonal insert allows full utilisation of beam section within the space required by the End Support WBD itself.

Plug-in component designed to create a square end plate at the open end of a Beam Section TP F 100 or a Beam Bracket/Cantilever bracket AK F 100. Variation 'T' with octagonal insert allows full utilisation of beam section within the space required by the End Support WBD itself.

Suitable for Sikla Channel System 41. Useful addition to Support Brackets for integration in crossbars and other structures composed of channels with a width of 41 mm.

Useful addition to Support Brackets for integration in crossbars and other structures composed of stainless steel channels.

Suitable for Sikla Channels MS 41. Useful addition to Support Brackets for integration in crossbars and other structures composed of hot-dipped galvanised channels.

Suitable for Sikla Channel System 41. Useful addition to Support Brackets for integration in crossbars and other structures composed of channels with a width of 41 mm.

Useful addition to Support Brackets for integration in crossbars and other structures composed of stainless steel channels.

Suitable for Sikla Channels MS 41. Useful addition to Support Brackets for integration in crossbars and other structures composed of hot-dipped galvanised channels.

Suitable for Sikla Channel System 41. Fixing Bracket with wide adjusting range for construction of cross bars and other structures composed of channels.

Designed for general mounting purposes as a direct lateral attachment link integrated in binding and bridging beams of concrete or wood, and for similar applications. It may serve as a connecting bracket for framework structures consisting of channels. Sprinkler systems: See 'Technical Data'. Types 60/30/90 and 90/60/90 are designed for attachment of pipes to wooden truss according to VdS CEA-standard 15.2.2.

Designed for general mounting purposes as a direct lateral attachment link integrated in binding and bridging beams of concrete or wood, and for similar applications. It may serve as a connecting bracket for framework structures consisting of channels.

Element for extending siMotec Pipe Shoes to Guided Pipe Shoes on stell beams with flange widths from 80-300 mm.

Element for modification of siMotec Sliding Pipe Shoes to Guided Pipe Shoes on siFramo F80 beam sections.

Using the Guiding Bracket FW F it's possible to guide Pipe Shoes with different plate thicknesses on siFramo F100 beam sections. The different versions of Type Z are suitable for the respective specified maximum plate thickness (t)and so additionally allow the absorption of lifting forces.

Fastener in HCP for creating a screw connection in combination with a nut or an existing thread.

Safety element for Sikla Channels to be used instead of simple washers. The Holding Bracket prevents the edges along the opening of the channels from bending, and ensures optimum load distribution. When loads are imposed along the Channels, Holding Brackets HK 41 provide for additional safety due to embossed teeth, which penetrate the channel. Suitable for single and double channels. Special blanking guarantee high safety and shear forces after reaching form closure, especially for bolted through connecting elements.

One-piece pipe clamp with 2-thread nut with M8 or M10 connection option for fastening pipes in supply systems. Suitable for wall, floor and ceiling mounting as well as for sound-decoupled pipe fastening, even for sound insulation requirements in accordance with DIN 4109. Time savings thanks to quick-release fastener. Thread stop prevents the connection nut from chipping off if not installed correctly.
